SV-ADAHRS-20X Installation and Configuration
SkyView System Installation Guide - Revision K 5-7
3. Feed the nylon washer over the body of the probe.
4. Hand-thread the nylon nut onto the threaded body of the probe. At this point, the nylon
washer should be sandwiched between the nylon nut and the inside of the fuselage.
5. Carefully tighten the nut using the 9/16” wrench.
6. Route and secure the probe wires to the location of the ADAHRS module. Keep wires
away from radios, ignition, and other noisy electronics.
7. Carefully insert the pins on the wires into the connector housing. Pins are not polarized
and lock into place when inserted correctly.
8. Connect the probe to the ADAHRS module.
If the OAT probe is installed correctly, there should be an outside air temperature reading on
the PFD.
Adjusting OAT Adjust
SkyView provides the ability to adjust the displayed OAT +/- 20F (11.1C). This adjustment is
applied across the OAT’s entire temperature range. This adjustment can be made under SETUP
MENU >HARDWARE CALIBRATION > ADAHRS CALIBRATION > OAT OFFSET.
PFD-Related Settings
Once the physical ADAHRS installation is complete, it may be necessary to configure PFD-
related ADAHRS settings for the SkyView system. All ADAHRS settings are automatically shared
between displays in multi-display systems.
Measurement Units
Set altitude, distance and speed, temperature, barometer, and pressure measurement units as
detailed in the How to Configure Displayed Units Section of this guide.
ADAHRS Source Selection
If the installation has more than one ADAHRS, enter the ADAHRS Source Selection Page (SETUP
MENU > PFD SETUP > ADAHRS SOURCE SELECTION) and specify the primary ADAHRS.
In systems with more than one ADAHRS, the one noted as ACTIVE is the primary. All other
properly functioning ADAHRS are noted as ONLINE.
The SkyView system automatically switches to a backup ADAHRS in the case of a
failure.
Airspeed Limitations
Use the values on this page to set IAS tape colors. Set V-speed (e.g., stall speed in landing
configuration) thresholds on the Airspeed Limitations Page (SETUP MENU > PFD SETUP >
AIRSPEED LIMITATIONS). The values on this page are default values that act as placeholders.
