Dynon Avionics SkyView - SkyView D37 Harness Pin-Out

Appendix C: Wiring and Electrical Connections
17-6 SkyView System Installation Guide - Revision K
SkyView D37 Harness Pin-Out
SkyView Display Male
D37 Pin
SV-HARNESS-D37 Wire Color
Description
1
Red
Power Input
2
Red with Yellow stripe
Backup Battery Input
3
Brown with Violet stripe
Serial Port 1 RX
4
Brown with Orange stripe
Serial Port 1 TX
5
Yellow with Violet stripe
Serial Port 2 RX
6
Yellow with Orange stripe
Serial Port 2 TX
7
Green with Violet stripe
Serial Port 3 RX
8
Green with Orange stripe
Serial Port 3 TX
9
Blue with Violet stripe
Serial Port 4 RX
10
Blue with Orange stripe
Serial Port 4 TX
11
Gray with Violet stripe
Serial Port 5 RX
12
Gray with Orange stripe
Serial Port 5 TX
13
Brown
Audio Output Left
14
Orange with Yellow stripe
Contact Input 3
15
Orange with Green stripe
Contact Input 4
16
Red
USB Power
17
Black
USB Ground
18
White
USB-
19
Green
USB+
20
Red
Power Input
21
Black
Ground
22
Black
Ground
23
Black
Ground
24
Black
Ground
25
Violet
Dim Input
26
White
Dim Output
27
Orange with Red stripe
Contact Input 2
28
Orange with Black stripe
Contact Input 1
29
Orange
SV-GPS-250 Power Output
30
Black
Ground
31
Gray
Audio Output Right
32
Do Not Connect
Do Not Connect
33
Do Not Connect
Do Not Connect
34
Do Not Connect
Do Not Connect
35
Do Not Connect
Do Not Connect
36
Do Not Connect
Do Not Connect
37
Do Not Connect
Do Not Connect
Table 55–SkyView Display Male D37 Pin-out with Harness Wire Colors
