Dynon Avionics SkyView - Example Lycoming;Continental 4-cylinder Carbureted

SV-EMS-220 Installation and Configuration
7-10 SkyView System Installation Guide - Revision K
EMS
Module
Output
Pin
Output
Current
Limit
Wire Color
Current Draw of Sensors that Use This Output
12V
15
80mA
Red
FloScan Fuel Flow Sensor (100403-001): 50mA
EI Fuel Flow Sensor (100403-003): 15mA
UMA Differential Fuel Pressure: 10mA
Rotax Honeywell Oil Pressure Sensor: 20mA
5V
18
300mA
White/Red
Kavlico pressure sensors: 5mA
3
rd
party trim and flaps position: 5mA
Manifold pressure sensor (100434-000): 10mA
Table 17- EMS Module Current Draw Limits for 5/12V Lines
Example Engine Sensor and Transducer Installations
This section contains example engine sensor and transducer installations for popular engines.
Each engine subsection listed on the following pages contains tables for each SV-EMS-220
connector and suggests a way to connect that engine’s required sensors to the EMS module.
These tables are based on the downloadable mapping and settings files available from Dynon’s
support forums and may need to be modified based on your particular installation.
Example Lycoming/Continental 4-cylinder Carbureted
Pin
EMS 37-pin Harness
Wire Color
Sensor (with Dynon part number if
applicable)
1
Red
Battery voltage (voltmeter input)
2
Yellow or Unwired
Not connected
3
Black
Ground
4
Purple/Blue
Elevator position potentiometer
5
Black
Ground
6
White/Yellow
Oil pressure (100411-002 or 101693-000)
7
White/Brown
Oil temperature (100409-000)
8
Brown
Fuel pressure (100411-000 or 101690-000)
9
Brown/Blue
Heated pitot status (contact input)
10
Brown/Yellow
Not connected
11
Orange
Not connected
12
Yellow
Not connected
13
Black
Ground
14
Yellow
Fuel flow (100403-003)
15
Red
Not connected
16
Black
Ground
17
Black
Ground
