SV-EMS-220 Installation and Configuration
SkyView System Installation Guide - Revision K 7-11
Pin
EMS 37-pin Harness
Wire Color
Sensor (with Dynon part number if
applicable)
18
White/Red
Manifold Pressure Sensor Power (+5 volt) /
Kavlico Pressure Sensors
19
White/Black
Not connected
20
Orange/Brown
Fuel level left (resistive)
21
Orange/Blue
Fuel level right (resistive)
22
Purple/Yellow
Flaps position potentiometer
23
Purple/Green
Carburetor temperature (100468-000)
24
Orange/Green
Ammeter shunt + (100412-000)
25
Orange/Purple
Ammeter shunt -
26
Green/Red
Manifold Pressure (100434-000)
27
Open
Not connected
28
Open
Not connected
29
Yellow/Green
Optional External Alarm Light
30
Black
Not connected
31
White/Orange
Not connected
32
White/Green
RPM Left (standard)
33
White/Blue
RPM Right (standard)
34
Blue
Not connected
35
Green
Not connected
36
Blue or Unwired
Not connected
37
Green or Unwired
Not connected
Table 18–Example Lycoming/Continental 4-cylinder Carbureted 37-pin Connector Sensor Map
Pin
EMS 25-pin Thermocouple
Harness Wire Color
Sensor (with Dynon part number if
applicable)
1
Open
N/A
2
Open
N/A
3
Open
N/A
4
Open
N/A
5
Open
N/A
6
Red
CHT 4 (J-type thermocouple, 100404-000*)
7
Red
EGT 4 (K-type thermocouple, 100405-000)
8
Red
CHT 3
9
Red
EGT 3
10
Red
CHT 2
11
Red
EGT 2
12
Red
CHT 1
13
Red
EGT 1
14
Open
N/A
15
Open
N/A
