Appendix B: Specifications
16-2 SkyView System Installation Guide - Revision K
SkyView Compatible Engine Sensors
Description
Range/Type
Fittings
Dynon P/N
Amps Shunt or
Ammeter Shunt
0-60 A
(can be configured to
display -60 A to +60 A)
2 each 1/4” Ring
Terminals
100412-000
Capacitance to
Voltage Converter for
Vans Capacitive
Plates
50 pF to 1000 pF
BNC connector to Van’s
RV fuel tank sensor
100654-000
Carburetor Air
Temperature
-50° F to 150° F
1/4-28 UNF
100468-000
CHT (for Jabiru)
J-Type Thermocouple
12mm Ring Terminal
100578-000
CHT (for Lycoming/
Continental/Superior)
J-Type Thermocouple
Bayonet 3/8-24 UNF
100404-000
EGT (for Jabiru)
K-Type Thermocouple
1/8” hole, Hose Clamp
3/4” – 1 3/4”
100405-002
EGT (for Lycoming/
Continental/Superior)
K-Type Thermocouple
1/8” hole, Hose Clamp,
1” – 2”
100405-000
EGT (for Rotax)
K-Type Thermocouple
1/8” hole, Hose Clamp
1/4” – 1 1/4”
100405-001
Fuel Flow Transducer
(EI FT-60)
0.6 GPH -70+ GPH
1/4” Female NPT
100403-003
Fuel Pressure
(carbureted)
0-30 PSI
1/8-27 NPT
100411-000
Fuel Pressure
(fuel injected)
0-80 PSI
1/8-27 NPT
100411-001
Manifold Pressure
(MAP)
0-60 In Hg
Nipple fitting: 1/4” ID
tubing recommended
100434-000
OAT Probe
-40° F to 150° F
3/8” hole in fuselage,
9/16” nut
100433-001
100433-002
100433-003
Oil Pressure
0-150 PSI
1/8-27 NPT
100411-002
Oil Temperature
(for Lycoming/
Continental/Superior)
-10° F to 300° F
5/8-18 UNF
100409-001
Oil Temperature (for
older Continental 0-
200s)
-10° F to 300° F
1/8-27 NPT
100409-000
Table 49–SkyView Compatible Engine Sensors
