Appendix E: Serial Data Output
19-12 SkyView System Installation Guide - Revision K
Sensor Type ( and
Name if applicable)
Units
Units Character
Example/Range
Temperature
°C*10
C
+1234C (123.4 °C)
Pressure
PSI*10
P
+1234P (123.4 PSI)
Level
Gallons*10
G
+1234G (123.4 gal)
Volts
volts*1000
V
+1234V (1.234 V)
Position (ELEV,
RUDDER, or AILERN)
Percent
T
+0012T (12%)
Position (FLAPS)
Degrees
T
+0012T (12 degrees)
Table 66 - GP Serial Output Format
As an example, the following is one line of DYNON EMS serial output data:
!3118354201079-01123112311226021021107XXXXXX000113000+0070046200707-060-046-
060-046+195+251+214+251+203+251+232+251-060-046+0100T+0018T+0000V+0107P
XXXXXXXXXXXXZZZZZZZZZZZZXXXXXXXXXXXX+0790P+0123CZZZZZZZZZZZZZZZZZZZZZZ5A
DYNON ADAHRS / SYSTEM / EMS Serial Data Output Combinations
DYNON ADAHRS + SYSTEM Serial Data Format
DYNON ADAHRS+SYSTEM output data alternates between DYNON ADAHRS data and DYNON
SYSTEM data. For example, the following is one cycle of DYNON ADAHRS+SYSTEM serial output
data where the first line is ADAHRS output and the next line is SYSTEM output:
!1122260511+890-05262380930+09843-015-01+1002+000+381171249+1491121699A7
!2122260512302+00101590+0500020050+16XXX30L00U02R000001110E6
DYNON ADAHRS + EMS Serial Data Format
DYNON ADAHRS+EMS output data alternates between DYNON ADAHRS data and DYNON EMS
data. For example, the following is one cycle of DYNON ADAHRS+EMS output data where the
first line is ADAHRS output and that is followed by EMS output:
!1122260511+890-05262380930+09843-015-01+1002+000+381171249+1491121699A7
