System Planning
2-4 SkyView System Installation Guide - Revision K
In order to provide the most reliable airspeed (and therefore attitude) performance, Dynon
Avionics STRONGLY RECOMMENDS the installation of a heated pitot probe in aircraft equipped
for IFR to prevent loss of airspeed data due to icing.
Location Requirements
SV-D1000 and SV-D700
Observe the following guidelines when choosing a location for a SkyView display:
 Displays require about 2.4” of free space behind the panel, depending on mounting
surface thickness.
 The SkyView Display Harness (SV-HARNESS-D37) extends about 3” from the back of the
display.
 Add one inch beyond the physically required volume for the display’s heat sinks and fans
to operate.
 Avoid placing the display near heater vents or any source of extremely hot air.
 The display should be easily viewable without any obstructions.
 Displays have no internal inertial sensors and do not need to be mounted in the same
orientation as the ADAHRS or other modules.
 Displays only support a landscape viewing orientation; do not mount in portrait
orientation.
 SkyView systems support up to four displays.
