1. Wire a serial receive line to the respective transmit line on the transponder. If you have
multiple SkyView displays, the serial transmit wire from the external transponder should
be connected to a SkyView serial receive wire on each display in parallel.
2. Ensure there is a shared ground between the D700/D1000 and the transponder.
3. Configure the serial port on each display appropriately under SETUP MENU > LOCAL
DISPLAY SETUP > SERIAL PORT SETUP.
4. Configure the serial port on the transponder appropriately. For a Garmin GTX 327/330,
the RS-232 output of the appropriate serial port should be set to REMOTE+TIS.
Gray-Code Transponder Installation
To use SkyView’s altitude encoder functionality with your Gray Code transponder:
1. Follow the installation instructions in the Encoder Serial-to-Gray Code Converter
Installation and Configuration Section.
2. Configure the serial port on each display according to the instructions on page 14-12.
Reference the Serial Port Configuration Section of this guide for serial port configuration
information.
Garmin SL30
If you are using a Garmin SL30 NAV/COM radio with SkyView:
1. Connect SL30 serial RX pin 4 (RxD1) to one of the SkyView serial TX pins on each display.
2. Connect SL30 serial TX pin 5 (TxD1) to one of the SkyView serial RX pins on each display.
3. Configure the serial port on each display appropriately under SETUP MENU > LOCAL
DISPLAY SETUP > SERIAL PORT SETUP.
4. Configure the serial port on the SL30 appropriately. On the SL30, the Indicator Head
Type should be set to NONE.
Dynon ADAHRS/EMS/SYSTEM/NMEA Data Outputs
To output real-time data to an external serial device, such as a serial data recorder, ELT, or
other device that accepts NMEA or Dynon formats:
1. Wire a serial transmit line from one display to the receive line on the external serial
device.
2. Ensure there is a shared ground between the D700/D1000 and the external serial
device.
3. Configure the serial port on the display appropriately under SETUP MENU > LOCAL
DISPLAY SETUP > SERIAL PORT SETUP, selecting the desired output data format.
USB Usage and Accessibility
It is useful to have the USB socket on the display’s wire harness accessible after
installation for file uploads and downloads.
The USB connector is used during the following operations:
