SV-D700 / SV-D1000 Installation and Configuration
4-8 SkyView System Installation Guide - Revision K
consequences. Damage caused by connecting such a battery will not be repaired
under warranty.
In the event of primary power loss, a fully charged backup battery can keep most
SkyView systems operating for at least 60 minutes. The backup battery provides
power for its connected display and that display’s attached SkyView modules and
the SV-GPS-250. It does not provide power for other displays or servos as they are
not powered by a display.
See the Homemade Wire Harness Considerations section for important
specifications that must be adhered to for the SV-BAT-320 to charge properly
when used with a non-Dynon harness.
SkyView Network Connectors
The two D9 connectors on the back of a SkyView display are SkyView network connectors. They
have identical pin-outs and are electrically connected inside the display (i.e., they are
completely interchangeable). Installers may use either connector or both connectors in SkyView
installations. Reference Table 56 on page 17-8 for SkyView Network Connector pin-out
information.
Note that these connectors are not serial port connectors.
Network Setup and Status
Once all SkyView modules are connected in a network, either in a bench top test or permanent
installation, turn the display(s) on. You will see the display boot up and the status LEDs on the
modules light up.
A tail number on the Aircraft Information Page (SETUP MENU > SYSTEM SETUP >
AIRCRAFT INFORMATION) is required for network configuration.
If you have more than one display in your SkyView system, the tail number only
needs to be set on the display that you initially perform the Network Configuration
on. At network configuration time, all other displays that are set to the default tail
number of DYNON will automatically have their settings and tail number
synchronized with the display the configuration is performed from. After
configuration, all displays’ tail numbers and settings will be synchronized, and
further setup tasks can be performed from any display.
Before you configure the SkyView network, the PFD and EMS pages will contain a
big red “X” over a black screen. You must configure the network before PFD and
EMS data is displayed on SkyView
Use the following procedure to configure a SkyView network:
