Table 61 - SV-XPNDR-26X Qualification Forms
SV-XPNDR-26X ADS-B Compliance
SV-XPNDR-26X transponder modules include support for Extended Squitter ADS-B out. The SV-
XPNDR-26X is a DO-260A change 2 compliant class B0 broadcast-only participant.
ADS-B Parameters Supported
The following table lists the ADS-B parameters that are transmitted by the SV-XPNDR-26X
transponder when connected to an appropriate GPS receiver.
Parameter
BDS Register
SPI
0,5
Emergency Indicator
0,5
Barometric Altitude
0,5
Quality Indicator (NIC)
0,5
Airborne
Position
Latitude
0,5
Longitude
0,5
Quality Indicator (NIC)
0,6
Surface Position
Latitude
0,6
Longitude
0,6
Surface Ground Speed
0,6
Surface Ground Track
0,6
Aircraft Identification
0,8
Airborne Ground Velocity
0,9
Emergency Status
6,1
Quality Indicator (NACp)
6,5
Quality Indicator (SIL)
6,5
Version Indicator
6,5
Surface Length/Width
6,5
Table 62 - SV-XPNDR-26X ADS-B Parameters Supported
