` Appendix C: Wiring and Electrical Connections
SkyView System Installation Guide - Revision K 17-15
Equipment identified as Category X – no test required
Equipment identified as Category X – no test required
Equipment identified as Category X – no test required
Equipment identified as Category C
TT22 Mode S Transponder (Dynon Avionics SV-XPNDR-261)
Heriot Watt Research Park, Riccarton, Currie, Scotland, EH14 4AP
Description of Conducted Tests
Equipment tested to Categories A2, C1
Low temperature ground survival
Low temperature short-time
operating
Low temperature operating
High temperature operating
High temperature short-time
operating
High temperature ground survival
Cooling air not required (+70°C operating without cooling air)
8,000 to 35,000 feet in 15 seconds
Equipment tested to Category C
Equipment tested to Category A
Equipment tested to Category B
Equipment tested to Category B type 5
Aircraft zone 2; type 3, 4, 5 to category S level M, type 1 (Helicopters) to
category U level G
Equipment identified as Category X – no test required
Equipment identified as Category X – no test required
Equipment identified as Category X – no test required
Equipment identified as Category X – no test required
Equipment identified as Category X – no test required
Equipment identified as Category X – no test required
Equipment tested to Category Z
Equipment tested to Category BX
Equipment tested to Category B
Audio frequency conducted
susceptibility
Equipment tested to Category B
Induced signal susceptibility
Equipment tested to Category AC
Radio frequency susceptibility
Equipment tested to Category TT
Equipment tested to Category B
Lightning induced transient
susceptibility
Equipment identified as Category XXXX – no test required
Equipment identified as Category X – no test required
