Appendix A: Maintenance and Troubleshooting
SkyView System Installation Guide - Revision K 15-3
10. Using a display that never left the aircraft (and is presumably configured and working
correctly):
It is important that this step is done from the correct display. If network
configuration is done from the repaired unit, it is possible for it to overwrite the
correct settings that are stored in your good display with the Dynon default
factory settings.
a. Confirm that the tail number under SYSTEM SETUP > AICRAFT INFORMATION is
set to the actual aircraft tail number, not DYNON.
b. Reconfigure SkyView Network under SETUP MENU > NETWORK SETUP >
CONFIGURE…
c. Confirm all SkyView Network components are found, including ALL displays that
are in the aircraft.
d. Exit Setup mode.
11. On the recently repaired display, confirm that the tail number under SYSTEM SETUP >
AICRAFT INFORMATION is now set to the actual aircraft tail number, not DYNON. This
implies that all settings and configurations have been synchronized from the other
display.
SV-ADAHRS-20X Modules
1. Reinstall the ADAHRS in the aircraft.
2. Reconnect all harnesses and connections as originally installed.
3. Power up the SkyView System.
4. From any display in the aircraft, reconfigure SkyView Network under SETUP MENU >
NETWORK SETUP > CONFIGURE…
5. Confirm all SkyView Network components are found, including the reinstalled ADAHRS.
6. If the ADAHRS is the same serial number as the one you returned for repair, no further
actions should be required. However, Dynon recommends double checking the
performance of magnetic heading and AOA calibration. If these do not seem to work as
well as they previously did, redo those calibrations.
7. If the ADAHRS is not the same serial number as the one you returned for repair, all
setup and calibration steps in the SV-ADAHRS-20X Installation and Configuration section
of the SkyView Installation manual should be performed as if the ADAHRS is being
installed for the first time.
Autopilot Servos
1. Reinstall the servo in the aircraft.
2. Reconnect all harnesses and connections as originally installed.
3. Power up the SkyView System.
4. From any display in the aircraft, reconfigure SkyView Network under SETUP MENU >
NETWORK SETUP > CONFIGURE…
5. Confirm all SkyView Network components are found, including the reinstalled servo.
