Appendix A: Maintenance and Troubleshooting
15-2 SkyView System Installation Guide - Revision K
Returning SkyView Components to Service after Repair
SkyView Network enabled components such as modules, servos, and displays are shipped in a
“like new” state after repair. To return a SkyView Network component to SkyView Network,
follow the following directions:
SV-D1000/D700 Display, when display is the ONLY display in the aircraft
1. Reinstall the display into the panel.
2. Reconnect all harnesses and connections as originally installed.
3. Power up the SkyView System.
4. If you have a settings backup on a USB memory stick:
a. Load settings backup via SETUP MENU > SYSTEM SOFTWARE > LOAD FILES.
b. Confirm that the tail number under SYSTEM SETUP > AICRAFT INFORMATION is
set to the actual aircraft tail number, not DYNON.
c. Reconfigure SkyView Network under SETUP MENU > NETWORK SETUP >
CONFIGURE…
d. Confirm all SkyView Network components are found.
e. Confirm all settings, calibrations, and behaviors are as expected. Dynon
recommends using the Installation Guide to walk through each set up section to
confirm proper system operation.
5. If you do not have a settings backup, use the SkyView Installation Guide to perform ALL
setup and configuration steps as if the entire system is being installed for the first time.
SV-D1000/D700 Display, when other display is part of a multi-display system in the
aircraft
1. Confirm that your OTHER (still installed) SkyView displays are running the latest system
software by comparing the version available at http://downloads.dynonavionics.com
with the version that is listed in SETUP MENU > SYSTEM SETUP > NETWORK SETUP >
NETWORK STATUS. If they are not the same, update these displays before proceeding
further. Instruction for updating your displays can be found in the Firmware Updates
and File Operations section of this manual.
2. Reinstall the repaired display into the panel.
3. Reconnect all harnesses and connections as originally installed.
4. Power up the SkyView System.
5. If you have settings backed up from the repaired display from its pre-repair state, load
them using SETUP MENU > SYSTEM SOFTWARE > LOAD FILES…
a. If you do not have setting backed up from the repaired display, skip to step 9.
6. Ensure that ALL settings under SETUP MENU > LOCAL DISPLAY SETUP are correct.
7. Set the tail number of the repaired display (SYSTEM SETUP > AICRAFT INFORMATION) to
DYNON.
8. Exit setup on the repaired display.
9. DO NOT change any settings on the recently repaired display.
