System Planning
SkyView System Installation Guide - Revision K 2-7
There are no module-to-module proximity requirements when installing multiple
SV-ADAHRS-20X modules in an aircraft. For example, one SV-ADAHRS-20X may be
installed on top of another SV-ADAHRS-20X module. Other installation location
requirements still apply.
The ADAHRS installation location should also adhere to the following requirements:
Avoid locations that are lower than the lowest point in the pitot/static system to reduce
the chance of allowing moisture to enter the module.
Avoid locations that are subject to severe vibration.
Avoid locations that are subject to rapid changes in temperature.
Avoid locations that are subject to extreme humidity.
Leave ample working room for electrical and pneumatic connections.
SV-EMS-220
Observe the following guidelines when choosing a location for an SV-EMS-220 Engine Monitor
module:
Do not install on the engine side of the firewall.
Avoid locations that are subject to severe vibration.
Avoid locations that are subject to extreme humidity.
Leave ample working room for electrical connections.
SkyView systems support one SV-EMS-220 per network. Future updates may include
support for more than one SV-EMS-220 for multiple engine support.
SV-GPS-250
Observe the following guidelines when choosing a location for an SV-GPS-250 GPS Receiver
module:
Optimal mounting location is a rigid surface on top of the aircraft.
Mounting location should be relatively level.
Avoid antenna shadows (i.e., obstructions that block the antenna’s view of the sky).
Do not locate the receiver within 3 feet of transmitting antennas.
All four of the SV-GPS-250 module’s wires should all be connected to each SkyView
system display for redundancy.
The SV-GPS-250 can be mounted inside the aircraft, however some signal
degradation will occur. If you are concerned with possible performance issues with
the intended installation location, verify GPS functionality at that location with a
temporary installation. For optimal performance, the GPS receiver must have a
clear view of the sky during maneuvers.
