` Appendix E: Serial Data Output
SkyView System Installation Guide - Revision K 19-3
Parameter
Start
Character
Position
Num
Chars
Range of
values /Units
Example/Notes
Turn Rate
35
3
000 to 999
1/10
degrees/sec
020 (2 degrees/sec)
Lateral g’s
Sign
38
1
‘+’ or ‘-‘
‘+’ means aircraft is
experiencing leftward lateral
acceleration
Lateral g’s
39
2
00 to 99
1/100 g
99 (.99 g’s)
Vertical g’s
Sign
41
1
‘+’ or ‘-‘
‘+’ means aircraft is
experiencing upward vertical
acceleration
Vertical g’s
42
2
00 to 99
1/10 g
99 (9.9 g’s)
Angle of
Attack
44
2
00 to 99
percent of stall
angle
10 (10 percent)
Vertical Speed
Sign
46
1
‘+’ or ‘-‘
‘+’ means aircraft is climbing
Vertical Speed
47
3
000 to 999
feet/minute *
10
042 (420 feet per minute )
OAT Sign
50
1
‘+’ or ‘-‘
OAT
51
2
00 to 99
°C
30 (30 °C)
Airspeed
(TAS)
53
4
0000 to 9999
1/10 knots
1234 (123.4 knots)
Barometer
Setting
57
3
000 to 400
1/100 inHg
offset from
27.50 inHg
400 (31.50 inHg)
Total range is 27.50 to 31.50
inHg
Density
Altitude Sign
60
1
‘+’ or ‘-‘
‘+’ means altitude is above sea
level
Density
Altitude
61
5
00000 to
99999
feet
12345 (12,345 feet)
Wind
Direction
66
3
000 to 359
degrees
magnetic
010 (10 degrees)
Wind Speed
69
2
00 to 99
knots
15 (15 knots)
