Eaton SmartWire-DT SWD Series User Manual

4 PKE-SWD-32, interface for motor-starter combination with PKE PKE12/32
4.9 Programming
110 SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com
Byte 2:
Motor current [%]
Byte 3:
Thermal motor image [%]
Byte 4:
Type of trip block, set time-lag class
Data bit Designation Description Notes
0-3 Ir Set value I
r
￫ Section 4.9.1.4, "Set value Ir", page 111
4-6
TRIPR =
Trip reason
Trip Reason ￫ Section 4.9.1.5, "Trip reason (TRIPR)", page
112
7
ACKR =
Acknowledge
required
ZMR manual function acknowl-
edgement required
0: No acknowledgement required
1: Acknowledgement of overload
required
￫ Section 4.9.2.1, "ZMR operating mode
manual", page 116
76543210
I-REL I-REL I-REL I-REL I-REL I-REL I-REL I-REL
Data bit
Designation Description Notes
0-7 I-REL Motor current [%] ￫ Section 4.9.1.6, "Motor current
[%] (I-REL)", page 113
76543210
TH TH TH TH TH TH TH TH
Data bit
Designation Description Notes
0-7 TH Thermal motor image [%] ￫ Section 4.9.1.7, "Thermal motor
image [TH]", page 113
76543210
– – CLASS CLASS CLASS TYPE TYPE TYPE
Data bit
Designation Description Notes
0-2 TYPE Control option part no. ￫ Section 4.9.1.8, "Type of trip
block (TYPE)", page 114
3-5
CLASS Set time lag ￫ Section 4.9.1.9, "Time delay
setting (CLASS)", page 114
6
Not used - -
7
Not used - -
