ECKELMANN UA 400 - Page 163

Firmware V3.15
21.04.2021
163/401
•
1.
2.
3.
4.
•
Menu6-2-4230Vinputs
230 V INPUTS ID: XXXXX Input Default
Input 1: XXXXXXXXXX Function of the digital input 1 D11/D12 1) DEFROST TIMER
Input 2: XXXXXXXXXX Function of the digital input 2 D21/D22 2) SOLLW.UMSCH
Input 3: XXXXXXXXXX Function of the digital input 3 D31/D32 3) MANUAL OFF
Input 4: XXXXXXXXXX Function of the digital input 4 D41/D42 4) EXTERNAL ALARM
XXXXXXXXXXXXXXXXXXX Freely configurable alarm text for digital input 4,
thedefaulttextis“CO2-Alarm”
Text CO2-Alarm
Inv. D1 XXX Inversion of digital input 1
, , (ON/OFF)
OFF
Inv. D2 XXX Inversion of digital input 2 OFF
Inv. D3 XXX Inversion of digital input 3 OFF
Inv. D4 XXX Inversion of digital input 4 OFF
Possible settings for the digital inputs:
ABTAUUHR defrost timer *
HANDABSCH. Manual shutdown of both zones
HANDABSCH. Z1Handabschaltung only Z1
HANDABSCH. Z2Handabschaltung only Z2
SOLLW.UMSCH.Toggle setpoint
SOLLW.UMSCH Toggle setpoint *
HANDABSCH. Manual shutdown of both zones
HANDABSCH. Z1Handabschaltung only Z1
HANDABSCH. Z2Handabschaltung only Z2
HANDABSCH. Manual shutdown of both zones *
HANDABSCH. Z1Handabschaltung only Z1
HANDABSCH. Z2Handabschaltung only Z2
FREMDALARM External alarm *
HANDABSCH.Manual shutdown of both zones
HANDABSCH. Z1Handabschaltung only Z1
HANDABSCH. Z2Handabschaltung only Z2
SOLLW.UMSCH.Toggle setpoint
*Factory setting
Menu 6-2-5 Sensor type
The changeover of the inputs is only intended for trained personnel as changes can also affect the
furtherfunctionalityofthecontroller.

