ECKELMANN VS 300 - Page 141

Parameter List and Menu Structure of VS 300
133
Doku-Version 2.05 - Firmware 2.10 - 15. September 2017
S Menu 3-3-4 LP/HP Control Day Control Loop 2
HP-CONT D POS: XXXXX Entry
Default
NT LT HP Dim.
tx - Max. XXX °C t
0
-/t
c
setpoint for CL2;
when setpoint shift activated:
max. t
0
-/t
c
setpoint for setpoint shift CL2
-50 - 45 -12 -38 25 °C
tu - Min. XXX min. tr-/ta for setpoint shift CL2 (only
shown when setpoint shift activated menu
3-3-2-a)
-50..35 -16 -40 25 °C
tx - Min. XXX min. t0-/tc setpoint for setpoint shift CL1
(only shown when setpoint shift activated
menu 3-3-2-a)
0..20 15 38 0 °C
tu - Max. XXX max. tr-/ta for setpoint shift CL2 (only
shown when setpoint shift activated menu
3-3-2-a)
0..20 15 38 0 °C
Dead band XX °C Control hysteresis 1 - 10 4 4 6 °C
Control const. XX °C Max. control error vor variable actuating
times
1 - 10 10 7 10 °C
Feuchteschieb XXX Humidity shift activated in CL2 (only
shown when humidity recording activated,
menu 3-1)
(N/Y) N N N -
S Menu 3-3-5 LP/HP Control Night Control Loop 2
LP/HP-CONT N POS: XXXXX Entry
Default
NT LT HP Dim.
tx-Max. XXX °C t
0
-/t
c
setpoint for CL2;
when setpoint shift activated:
max. t
0
-/t
c
setpoint for setpoint shift CL2
-50 - 45 -10 -38 25 °C
tu - Min. XXX min. tr-/ta for setpoint shift CL2 (only
shown when setpoint shift activated menu
3-3-2-a)
-50..35 -16 -40 25 °C
tx - Min. XXX min. t0-/tc setpoint for setpoint shift CL2
(only shown when setpoint shift activated
menu 3-3-2-a)
0..20 15 38 0 °C
tu - Max. XXX max. tr-/ta for setpoint shift CL2 (only
shown when setpoint shift activated menu
3-3-2-a)
0..20 15 38 0 °C
Dead band XX °C Control hysteresis 1 - 10 4 4 6 °C
Control const. XX °C Max. control error vor variable actuating
times
1 - 10 10 7 10 °C
Feuchteschieb XXX Humidity shift activated in CL2 (only
shown when humidity recording activated,
menu 3-1)
(N/Y) N N N -
