F9, F9 Express Fetal & Maternal Monitor User Manual Fetal Monitoring Display
- 105 -
8.2.1 Data Saving
When the START key is pressed, the monitor saves data of the previous ID in a file, and then
clears it from the main interface. The main interface only displays the new patient‟s data. During
monitoring, the data is saved every 10 minutes. All data of the same patient is saved in a file (the
maximum duration is 24 hours, the rest data is saved in another file.)
The files are stored in the monitor. When the data amount reaches the maximum capacity (300
files or approximately 60-hour), the monitor deletes the oldest file(s) automatically.
When the network version is ETHERNET 1.4, if the central station disconnects with the fetal
monitor in one minute, the monitoring data will be re-uploaded to the central station after
re-connection, if the disconnection is over one minute, then the monitoring data can't be uploaded
to the central station.
8.2.2 *Searching for a File
When the USB facility is disabled, the searching key under the traces is used to search
for a patient‟s data file saved in the monitor.
To search for a patient,
1 Select the searching key to open the file list. It contains six sets of most recent patients‟ ID,
name and start time of monitoring. Select the required item, this file is loaded to the main
interface immediately.
Figure 8-3 File List
If the required file is not in this list,
2 Select MORE to open the Patient Searching window.
