Position
Axilla
Accessory
TEMP transducer
NOTE:
The essential performance is marked with an asterisk *.
A1.4 Recorder Specifications
Paper
Z-fold, thermosensitive
(compatible with GE and PHILIPS recorder papers)
Paper width
152mm (GE), 150mm (PHILIPS)
Effective printing width
110mm (American Standard)
120mm (International Standard)
FHR printout width
70mm (American Standard)
80mm (International Standard)
FHR scaling
30bpm/cm (American Standard)
20bpm/cm (International Standard)
TOCO printout width
40mm
TOCO scaling
25%/cm
Printing speed
Standard Speed(Real-Time Traces)
1 cm/min, 2 cm/min, 3 cm/min
Fast Print Speed(Stored Traces)
Up to 15mm/sec
Accuracy of data
± 5% (X axis)
Accuracy of data
± 1% (Y axis)
Resolution
8 dots/mm
Record Information
FHR1 trace/mark, FHR2 trace/mark, TOCO trace,
AFM trace/black mark, fetal movement mark, event
mark (and annotation), AUTO-zero symbol, alarm
indicator, SOV alarm indicator, US1 and US2 signal
loss alarm indicator, wired/wireless monitoring status
mark, date, time, printing speed, ID, name, FHR2
Offset, HR, SpO
2
, SYS, DIA, MAP, PR, TEMP, CTG
analysis results etc.
