F9, F9 Express Fetal & Maternal Monitor User Manual Introducing the Monitor
- 27 -
2.3.12 NIBP Cuff
Figure 2-19 NIBP Cuff Figure 2-20 Cuff Extension Tube
2.3.13 TEMP Sensor
Figure 2-21 TEMP Transducer
1 TEMP Sensor
2 TEMP Connector
1
2
1
2
1 NIBP Cuff
2 Cuff Extension Tube
