F9, F9 Express Fetal & Maternal Monitor User Manual Alarms
- 59 -
MAP High Alarm Limit
21 mmHg ~ 235 mmHg, in increments of 1
(2.8 kPa ~31.3 kPa, in increments of 0.1)
110 mmHg
(14.8 kPa)
MAP Alarm Delay
0 second, not adjustable
0 second
MAP Alarm Level
Medium, not adjustable
Medium
TEMP Alarm
On, Off
On
TEMP Low Alarm Limit
0 ºC ~ +49.9 ºC, in increments of 0.1
+36.0 ºC
TEMP High Alarm Limit
+0.1 ºC ~ +50.0 ºC, in increments of 0.1
+39.0 ºC
TEMP Alarm Delay
0 second, not adjustable
0 second
TEMP Alarm Level
Medium, not adjustable
Medium
NOTE:
The upper limit must be higher than the lower limit. When setting the upper limit, you do
not have access to the options that are lower than the preset lower limit, and vice versa.
4.14 Alarm Messages
4.14.1 Fetal Monitoring Alarm Messages
During fetal monitoring, the monitor gives alarms for the situations that need the physicians to
pay attention to. The alarm messages are listed below.
Patient Alarm Messages
Alarm Message
Source
Cause
Countermeasure
Medium Level
**FHR1 HIGH or
** FHR1 xxx > yyy,
**FHR2 HIGH or
** FHR2 xxx > yyy
**DFHR HIGH or
**DFHR xxx > yyy
US
FHR1, FHR2 or DECG
measuring result (xxx) is
higher than the set upper limit
(yyy) and the alarm delay time
of the upper limit is out.
Check if the alarm limits are
suitable; check the patient’s
condition.
**FHR1 LOW or
** FHR1 xxx < yyy,
**FHR2 LOW or
** FHR2 xxx < yyy
**DFHR LOW or
**DFHR xxx > yyy
US
FHR1, FHR2 or DECG
measuring result (xxx) is lower
than the set lower limit (yyy)
and the alarm delay time of the
lower limit is out.
Technical Alarm Messages
Alarm Message
Source
Cause
Countermeasure
