F9, F9 Express Fetal & Maternal Monitor User Manual Introducing the Monitor
- 26 -
2.3.9 IUP Catheter
Figure 2-16 IUP Catheter
2.3.10 ECG Cable
Figure 2-17 3-Lead ECG Cable
2.3.11 SpO
2
Sensor
Figure 2-18 SpO
2
Transducer
1
2
1 Interface to Connecting
Cable
2 Catheter
1 ECG Connector
2 ECG Fastener
3 Lead Wire
2
1 3
1 SpO
2
Sensor
2 SpO
2
Connector
1
2
