F9, F9 Express Fetal & Maternal Monitor User Manual Product Specifications
- 154 -
Appendix 1 Product Specifications
A F9, F9 Express Fetal/Maternal Monitor
A1.1 Environmental Specifications
The monitor may not meet the performance specifications given here if stored or used outside the
specified temperature and humidity ranges.
Working
Temperature
+5 ºC ~ + 40 ºC ( +41 ºF ~ +104 ºF)
Relative Humidity
15% ~ 93% (non-condensing)
Atmospheric Pressure
86 kPa ~ 106 kPa
Transport and Storage
Temperature
-20 ºC ~ +55 ºC (-4ºF ~ +131 ºF)
Relative Humidity
15% ~ 93% (non-condensing)
Atmospheric Pressure
70 kPa ~ 106 kPa
A1.2 Physical Specifications
Monitor
Dimensions and Weight
Size (depth x width x height)
347mm x 330mm x 126mm
Weight
F9: Approx. 5.5 kg
F9 Express: Approx. 6.3 kg
Power Supply
Operating Voltage
100V-240V~
Operating Frequency
50Hz/60Hz
Input Power
1.0A-0.5A
Battery
14.8VDC/5000mAh
Standards Compliance
IEC 60601:2005+A1:2012, EN 60601-1:2006+A1:2013,
IEC 60601-1-2:2014, EN 60601-1-2:2015,
IEC/EN 60601-2-27,
IEC/EN 60601-2-37,
IEC/EN 60601-2-49,
IEC 80601-2-30,
ISO 80601-2-61,
ISO 80601-2-56,
AAMI/ANSI EC13
Anti-electric Shock Type
Class I equipment with internal power supply
