F9, F9 Express Fetal & Maternal Monitor User Manual Maternal Monitoring Display
- 140 -
10.2 Maternal Monitoring Traces
Figure 10-4 Maternal Monitoring Traces
1
FHR1 Trace
2
FHR2 Trace
3
HR Trace
4
AFM Trace
5
TOCO Trace
6
ECG Trace
7
SpO
2
Waveform
F9 Express displays both maternal monitoring traces and fetal monitoring traces on the same
screen. The maternal monitoring traces include ECG waveform and SpO
2
waveform. The fetal
monitoring traces are the same as traces of F9, refer to 8.1 Traces for more information.
10.3 Maternal Vital Sign List
The maternal vital sign list keeps records of the recent maternal vital signs and the measuring
time. A start mark and the date appear when a new monitoring begins.
In maternal-fetal display mode, the list contains the time, SYS, DIA and MAP numerics of every
measurement.
1
2
3
4
5
6
7
