F9, F9 Express Fetal & Maternal Monitor User Manual Introducing the FTS-3 Fetal Telemetry
System
- 39 -
19
Battery Indicator
Indicate battery level.
20
TOCO-E Display
1. Display “TOCO/DECG” when connected to
DECG cable;
2. Display “TOCO/MECG” when connected to
MECG cable;
3. Display “TOCO” when not connected to DECG
cable or MECG cable.
3.1.3 Accessories
 FTS-3 DECG Cable
Figure 3-8 FTS-3 DECG Cable
WARNING
When connecting the fetal spiral electrode to the DECG cable, make sure that you have
chosen the correct connector for the fetal spiral electrode according to the marking on
the DECG cable.
2
1
1 DECG Cable Plug
2 DECG Cable Connector
