F9, F9 Express Fetal & Maternal Monitor User Manual Introducing the Monitor
- 20 -
2.2.1 Keys
Figure 2-6 Keys and Control Knob
The Monitor is a user-friendly device with operation conducted by a few keys on the front panel
and the control knob. Their functions are as follows:
(1) *START
Function: Start monitoring or return to the main interface
Press this key to start monitoring (on the main interface) or return to main interface (in
information inputting menu, reviewing menu, searching menu or setup menus).
(2) SILENCE
Function: Silence/reset
Press this key to disable the current auditory alarm manifestation, and re-enable the monitor‟s
response to new abnormal patient condition.
(3) AUTO ZERO
Function: TOCO/IUP zero
Adjust the external TOCO contractions trace/numeric to preset unit (external monitoring
contractions) or the IUP trace/numeric to reference point 0 (internal monitoring contractions).
(4) MARK
Function: Record an event.
Press this key to make an event mark or open the smart note list.
(5) PRINT
Function: Start/stop printing
Press this key to toggle between starting and stopping printing.
