Configuring Protocol-based VLANs

30-19

show interfaces protocol-vlan protocol-group

This command shows the mapping from protocol groups to VLANs for the selected

interfaces.

Syntax

show interfaces protocol-vlan protocol-group [interface]

interface

• ethernet unit/port

- unit - Stack unit. (Range: 1)

- port - Port number. (Range: 1-28)

• port-channel channel-id (Range: 1-32)

Default Setting

The mapping for all interfaces is displayed.

Command Mode

Privileged Exec

Example

This shows that traffic entering Port 1 that matches the specifications for protocol

group 1 will be mapped to VLAN 2:

Console#show interfaces protocol-vlan protocol-group

Port ProtocolGroup ID Vlan ID

---------- ------------------ -----------

Eth 1/1 1 vlan2

Console#
