Quality of Service
14-4
14
Web – Click QoS, DiffServ, then click Add Class to create a new class, or Edit Rules
to change the rules of an existing class.
Figure 14-1 Configuring Class Maps
CLI - This example creates a class map call “rd-class,” and sets it to match packets
marked for DSCP service value 3.
Console(config)#class-map rd_class match-any 32-2
Console(config-cmap)#match ip dscp 3 32-3
Console(config-cmap)#exit
Console(config)#access-list ip mask-precedence in 23-6
Console(config-ip-mask-acl)#mask any any dscp 23-6
Console(config-ip-mask-acl)#
