Configuring Quality of Service Parameters

14-3

Match Class Settings

• Class Name – List of class maps.

• ACL List – Name of an access control list. Any type of ACL can be specified,

including standard or extended IP ACLs and MAC ACLs. (Range: 1-16 characters)

• IP DSCP – A DSCP value. (Range: 0-63)

• IP Precedence – An IP Precedence value. (Range: 0-7)

• VLAN – A VLAN. (Range:1-4093)

• Add – Adds specified criteria to the class. Up to 16 items are permitted per class.

• Remove – Deletes the selected criteria from the class.
