show policy-map interface

32-9

Example

show policy-map interface

This command displays the service policy assigned to the specified interface.

Syntax

show policy-map interface

interface

input

interface

• ethernet unit/port

- unit - Stack unit. (Range: 1)

- port - Port number. (Range: 1-28)

• port-channel channel-id (Range: 1-32)

Command Mode

Privileged Exec

Example

Console#show policy-map

Policy Map rd_policy

class rd_class

set ip dscp 3

Console#show policy-map rd_policy class rd_class

Policy Map rd_policy

class rd_class

set ip dscp 3

Console#

Console#show policy-map interface ethernet 1/5

Service-policy rd_policy input

Console#
