Class of Service Commands
31-12
31
Default Setting
The DSCP default values are defined in the following table. Note that all the
DSCP values that are not specified are mapped to CoS value 0.
Command Mode
Interface Configuration (Ethernet, Port Channel)
Command Usage
• The precedence for priority mapping is IP Port, IP Precedence or IP DSCP,
and default switchport priority.
• DSCP priority values are mapped to default Class of Service values according
to recommendations in the IEEE 802.1p standard, and then subsequently
mapped to the eight hardware priority queues.
• This command sets the IP DSCP priority for all interfaces.
Example
The following example shows how to map IP DSCP value 1 to CoS value 0:
show map ip port
This command shows the IP port priority map.
Syntax
show map ip port [interface]
interface
• ethernet unit/port
- unit - Stack unit. (Range: 1)
- port - Port number. (Range: 1-28)
• port-channel channel-id (Range: 1-32)
Table 31-6 Mapping IP DSCP to CoS Values
IP DSCP Value CoS Value
00
81
10, 12, 14, 16 2
18, 20, 22, 24 3
26, 28, 30, 32, 34, 36 4
38, 40, 42 5
48 6
46, 56 7
Console(config)#interface ethernet 1/5
Console(config-if)#map ip dscp 1 cos 0
Console(config-if)#
