Class of Service
13-12
13
Click Priority, IP Port Priority. Enter the port number for a network application in the
IP Port Number box and the new CoS value in the Class of Service box, and then
click Apply.
Figure 13-9 IP Port Priority
CLI – The following example globally enables IP Port Priority service on the switch,
maps HTTP traffic (on port 1) to CoS value 0, and then displays the IP Port Priority
settings.
* Mapping specific values for IP Port Priority is implemented as an interface configuration
command, but any changes will apply to the all interfaces on the switch.
Console(config)#map ip port 31-8
Console(config)#interface ethernet 1/1 24-1
Console(config-if)#map ip port 80 cos 0 31-9
Console(config-if)#end
Console#show map ip port ethernet 1/5 31-12
TCP port mapping status: disabled
Port Port no. COS
--------- -------- ---
Eth 1/ 1 80 0
Console#
