Address Table Commands

28-4

mac-address-table aging-time

This command sets the aging time for entries in the address table. Use the no form

to restore the default aging time.

Syntax

mac-address-table aging-time seconds

no mac-address-table aging-time

seconds - Aging time. (Range: 10-1000000 seconds; 0 to disable aging)

Default Setting

300 seconds

Command Mode

Global Configuration

Command Usage

The aging time is used to age out dynamically learned forwarding information.

Example

show mac-address-table aging-time

This command shows the aging time for entries in the address table.

Default Setting

None

Command Mode

Privileged Exec

Example

Console(config)#mac-address-table aging-time 100

Console(config)#

Console#show mac-address-table aging-time

Aging time: 300 sec.

Console#
