Class of Service Commands

31-14

Example

Related Commands

map ip precedence (Global Configuration) (31-9)

map ip precedence (Interface Configuration) (31-10)

show map ip dscp

This command shows the IP DSCP priority map.

Syntax

show map ip dscp [interface]

interface

• ethernet unit/port

- unit - Stack unit. (Range: 1)

- port - Port number. (Range: 1-28)

• port-channel channel-id (Range: 1-32)

Default Setting

None

Command Mode

Privileged Exec

Console#show map ip precedence ethernet 1/5

Precedence mapping status: disabled

Port Precedence COS

--------- ---------- ---

Eth 1/ 5 0 0

Eth 1/ 5 1 1

Eth 1/ 5 2 2

Eth 1/ 5 3 3

Eth 1/ 5 4 4

Eth 1/ 5 5 5

Eth 1/ 5 6 6

Eth 1/ 5 7 7

Console#
