GVRP and Bridge Extension Commands

30-5

show garp timer

This command shows the GARP timers for the selected interface.

Syntax

show garp timer [interface]

interface

• ethernet unit/port

- unit - Stack unit. (Range: 1)

- port - Port number. (Range: 1-28)

• port-channel channel-id (Range: 1-32)

Default Setting

Shows all GARP timers.

Command Mode

Normal Exec, Privileged Exec

Example

Related Commands

garp timer (30-4)

Console#show garp timer ethernet 1/1

Eth 1/ 1 GARP timer status:

Join timer: 20 centiseconds

Leave timer: 60 centiseconds

Leaveall timer: 1000 centiseconds

Console#
