Priority Commands (Layer 3 and 4)

31-13

Default Setting

None

Command Mode

Privileged Exec

Example

The following shows that HTTP traffic has been mapped to CoS value 0:

Related Commands

map ip port (Global Configuration) (31-8)

map ip port (Interface Configuration) (31-9)

show map ip precedence

This command shows the IP precedence priority map.

Syntax

show map ip precedence [interface]

interface

• ethernet unit/port

- unit - Stack unit. (Range: 1)

- port - Port number. (Range: 1-28)

• port-channel channel-id (Range: 1-32)

Default Setting

None

Command Mode

Privileged Exec

Console#show map ip port

TCP port mapping status: disabled

Port Port no. COS

--------- -------- ---

Eth 1/ 5 80 0

Console#
