MANUAL ELDES ESIM264 V2.0 33
5.4.6 Zones
NOTE: Colons, semi-colon characters, parameter names and/or values are not allowed in zone alarm texts, eg. PSW, STATUS, ON, OFF etc.
SMS text:
XXXX_Z1:NewAlarmText;Z2:NewAlarmText;Z3:NewAlarmText;
Z4:NewAlarmText;Z5:NewAlarmText;Z6:NewAlarmText;Zn:NewAlarmText
Menu path:
OK → CONFIGURATION → ZONES → WIRED ZONES → ZONE [1... 12] → NAME
OK → CONFIGURATION → ZONES → WIRELESS ZONES → RF ZONE [1... 16] → NAME
OK → CONFIGURATION → ZONES → KEYBOARD ZONES
→ [1ST... 4TH] KEYBOARD ZONE → NAME
OK → CONFIGURATION → ZONES → EPGM ZONES → EPGM ZONE [1... 16] → NAME
N/A
Please, refer to chapter 5.4.9 Info SMS.
Menu path:
OK → VIOLATED ZONES → ZONE [1... 44]
For violated zone Z1 - Z12 indication, please, check the zone LED indicators on
EKB3 device. For violated high zone Z13 - Z44 indication, please, refer to chapter
6.1 Trouble Indication.
EKB2
EKB2
EKB3
EKB3
Each secured zone has an alarm text which is sent by SMS message in case of alarm. Manu-
facturer default zone alarm text: Z1 - Door sensor triggered, Z2 - Windows sensor triggered, Z3
- Fire sensor triggered, Z4 - Motion1 sensor triggered, Z5 - Motion2 sensor triggered, Z6 - Motion3
sensor triggered etc.
Alarm text can be edited by SMS or ELDES Conguration Tool software only. The length of zone
alarm text for each zone can be up to 24 characters including <space> symbol.
This feature provides the list of violated zones.
Set Zone Alarm Text
List Violated Zones
SMS
SMS
NOTE: Due to security reasons it is recommended to restore the violated zone before arming the alarm system. In order to arm
the alarm system despite violated zone presence, you can set tup the zone to operate under Force mode or bypass it.
