1. General Information
1.1 Functionality
ESIM264 – micro-controller based alarm system for houses, cottages, country homes, garages and other buildings, also capable of
managing electrical appliances via cellular GSM/GPRS network. It can also be used as Intercom system.
The system can be used in the following applications:
• Property security;
• Alarm switch;
• Thermostat, heating and air-conditioner control, temperature monitoring;
• Lighting, garden watering, water pump and other electrical equipment control via SMS messages;
• Remote listening to what is happening in the secured area;
• Main 230V power status with SMS message;
• Two-way intercom device via GSM network.
1.2 Compatible Device Overview
Wired Devices
Device Description Max. Connectable Devices
EKB2 LCD keyboard 4*
EKB3 LED keyboard 4*
EA1 Audio output module with 3,5mm jack 1**
EA2 Audio amplier module 1W 8Ω 1**
EPGM1 16 zone and 2 PGM output expansion module 1
EPGM8 8 PGM output expansion module 1**
Wireless Devices
Device Description Max. Connectable Devices
EWT1 Wireless transmitter-receiver extension with external antenna (access point) 1
EW1**** Wireless 2 zone and 2 PGM output expansion module 16***
EWP1**** Wireless PIR movement sensor 16***
EWD1**** Wireless magnetic door contact 16***
EWK1**** Wireless key-fob with 4 buttons 16***
EWS1**** Wireless indoor siren 16***
EWS2**** Wireless outdoor siren 16***
* - A mixed combination of EKB2 and EKB3 keyboards is supported. The combination can consist of up to 4 keyboards in total.
** - Only 1 of these modules can be connected at a time.
*** - A mixed combination of wireless devices is supported. The combination can consist of up to 16 wireless devices in total.
**** - EWT1 module for ESIM264 system is required to operate with the wireless devices.
