7.2 EKB3 - LED Keyboard
EKB3 is a LED keyboard intended for using with ESIM264 alarm system.
Main EKB3 keyboard features:
• arms and disarms the alarm system
• enables and disables Stay mode
• congures system parameters
• displays system status information by LED indicators
• informs about system status via built-in mini buzzer
The system conguration is performed by accessing EKB2 menu and entering the required values. ESIM264 system allows to connect
up to 4 EKB3 keyboards.
7.2.1 Technical Specications
7.2.1.1 Electrical & Mechanical Characteristics
Power Supply 12-14V 150mA max
Maximum Keyboard Connection Cable Length 100 m.
Dimensions 140x100x18mm
Range of Operating Temperatures -30...+55ºC
7.2.1.2 LED Funcionality
ARMED Alarm system is armed /Conguration mode
READY System is prepared for arming
SYSTEM System troubles / valid command is being entered
BYPS Zone bypass mode
1-12 Violated zone
7.2.1.3 Keys Functionality
[BYPS] Zone bypass mode
[CODE] Additional options - system trouble list / violated high zone indication / violated tamper indication
[*] Conguration mode (when typed as a 1st character) / cancel command (when typed as a 2nd character) / keyboard
partition switch (if enabled)
[#] Conrm (enter) command
[0] ... [9] Command typing
[STAY] (currently inactive)
[INST] (currently inactive)
7.2.1.4 Connector Functionality
AUX+ Positive 12-14V power supply contact
AUX- Negative 12-14V power supply contact
G RS485 interface for communication (green wire)
Y RS485 interface for communication (yellow wire)
COM Common contact
Z1 Security zone
Z2 N/A
