MANUAL ELDES ESIM264 V2.0 89
7.2.3 Operation Description
The green LED READY indicates that no zones are violated or no troubles are present and the system is prepared for arming. LED
SYSTEM lights up or ashes in case of zone violation or if system troubles are present. The alarm system cannot be armed until the
troubles are removed or violated zone (-s) is restored, bypassed or set up to operate under Force mode. The following troubles allow
system arming when present:
• backup battery problem;
• main power supply failure;
• date & time not set;
• GSM connection problem.
The built-in mini buzzer uses two types of sound signals – three short beeps and one long beep. Three short beeps stand for success-
fully carried out conguration command, one long beep – for invalid conguration command. In addition, the mini-buzzer provides
continuous short beeps in case of alarm.
EKB3 keys have a LED back-light, therefore it is possible to use this keyboard even in dark premises. In case of alarm the keyboard
back-light turns on and lasts until the system is disarmed. The back-light lasts for 3 minutes after the last key-stroke while the system
is disarmed.
7.2.3.1 EKB3 Zone & Tamper
Keyboard EKB3 has one built-in zone Z1 and one tamper button. By default, the keyboard zone Z1 is disabled. The keyboard zone
can be enabled by SMS, EKB2 keyboard, EKB3 keyboard and ELDES Conguration Tool. When Z1 is enabled, it operates like any other
system zone, therefore a sensor can be connected to it. In addition, Z1 and COM contacts must be connected with resistor of 5,6kΩ
nominal.
The tamper button is intended for monitoring the enclosure status of EKB3, therefore the system causes alarm if the enclosure is il-
legally opened. Keyboard zone Z1 must be enabled and resistor connected even if the tamper button alone is required.
7.2.3.2 Arming & Disarming
The arming and disarming process is performed by entering a valid keyboard password. The default keyboard password is 1111.
When the system is being armed, the red LED ARMED is illuminated continously and the system initiates the countdown, indicated
by short beeps, intended for user to leave the premises. If the user does not leave the premises before the countdown is complete
the system switches to Stay mode.
After user enters the secured premises, the system begins the countdown intended to enter a valid keyboard password. After the
successful disarm process LED ARMED is switched o. In case user does not ener a valid keyboard password during the countdown,
the system causes alarm and the LED of violated zone (-s) is illuminated continously.
NOTE: Arming & disarming can only be performed using a keyboard password assigned to the same partition as the keyboard.
7.2.3.3 Keyboard Partition
Any EKB3 keyboard can be assigned to one of two available partitions. Every system keyboard assigned to dierent partition can
operate independently from each other. The keyboard partition can be assigned:
• permanently - by EKB2 keyboard, EKB3 keyboard and ELDES Conguration Tool;
• temporally - by EKB2 keyboard and EKB3 keyboard using keyboard partition switch feature. The partition automatically
switches back to previous partition in 3 minutes after the last key-touch/key-stroke.
In order to nd out the keyboard’s partition, please, check the position of illuminated LEDs ARMED and READY. If any of these LEDs is
illuminated on the LED section A, the keyboard is assigned to partition 0, if on the B section – the keyboard is assigned to partition 1.
NOTE: The system can be congured using only one keyboard at a time regardless of the assigned keyboard partition. The ash-
ing LED SYSTEM indicates an inactive EKB3 keyboard while CONFIGURATION MODE stays activated on another keyboard of
any partition.
NOTE: The conguration is disabled while any system partition is armed.
See also chapter 5.4.16 Partitions.
