MANUAL ELDES ESIM264 V2.0 45
SMS
SMS text:
XXXX_Cn:NewOutputName
Value: Cn – PGM output number, range – [C1... C44]
Example: 1111_C3:Pump
EKB2
Menu path:
OK → CONFIGURATION → PGM OUTPUTS → PGM OUTPUTS → OUTPUT [1... 12] → NAME
OK → CONFIGURATION → PGM OUTPUTS → RF OUTPUTS → RF OUTPUT [1... 32] → NAME
EKB3
N/A
SMS
SMS text:
XXXX_Cn:ON
Value: Cn – PGM output number, range – [C1... C44]
Example: 1111_Pump:ON
EKB2
Menu path:
OK → CONFIGURATION → PGM OUTPUTS →
PGM OUTPUTS → OUTPUT [1... 12] → STATUS → ENABLE
OK → CONFIGURATION → PGM OUTPUTS →
RF OUTPUTS → RF OUTPUT [1... 32] → STATUS → ENABLE
EKB3
Enter parameter 61, PGM output number & parameter status value:
[61xx1#]
Value: xx – PGM output number, range – [01... 44]
Each PGM output has a name. Manufacturer default PGM output names: C1 – Controll1, C2 –
Controll2, C3 – Controll3, C4 – Controll4 etc.
PGM output name can be edited by SMS or ELDES Conguration Tool software only. The length
of each PGM output name can be up to 10 characters.
This command turns on a specied PGM output and sets its‘ status to ON on system startup.
PGM Output Name
Turn ON PGM Output
/ Set PGM Output
Startup Status (ON)
5.4.7 PGM Outputs
NOTE: Space, colon, semi-colon characters, parameter names and/or values are not allowed in PGM output names, eg. PSW,
STATUS, ON, OFF etc.
XXXX_OutputName:ON
or
