Eldes ESIM264 - Page 46

46
SMS
SMS text:
XXXX_Cn:OFF
Value: Cn – PGM output number, range – [C1... C44]
Example: 1111_C2:OFF
EKB2
Menu path:
OK → CONFIGURATION → PGM OUTPUTS →
PGM OUTPUTS → OUTPUT [1... 12] → STATUS → DISABLE
OK → CONFIGURATION → PGM OUTPUTS →
RF OUTPUTS → RF OUTPUT [1... 32] → STATUS → DISABLE
EKB3
Enter parameter 61, PGM output number & parameter status value:
[61xx0#]
Value: xx – PGM output number, range -[01... 44]
SMS
SMS text:
XXXX_Cn:ON:HH.MM.SS
Value: Cn – PGM output number, range – [C1... C44], HH – hours, range – [00...
23], MM – minutes, range – [00... 59], SS – seconds, range [00... 59].
Example: 1111_C3:ON:13.23.48
EKB2
N/A
EKB3
N/A
SMS
SMS text:
XXXX_Cn:OFF:HH.MM.SS
Cn – PGM output number, range – [C1... C44], HH – hours, range – [01... 23],
MM – minutes, range – [01... 59], SS – seconds, range [01... 59].
Example: 1111_Pump:OFF:14.50.22
EKB2
N/A
EKB3
N/A
This command turns on a specied PGM output and sets its‘ status to OFF on system startup.
The system has an internal RTC (real time clock) allowing to set the timer for turning on a
particluar PGM output at a set time.
This command allows to set the timer for turning o a particluar PGM output at a set time.
Turn OFF PGM Output
/ Set PGM Output
Startup Status (OFF)
Turn ON PGM
Output by Timer
Turn OFF PGM
Output by Timer
NOTE: Value [00.00.00] is invalid
XXXX_OutputName:OFF
or
XXXX_OutputName:ON:HH.MM.SS
or
XXXX_OutputName:OFF:HH.MM.SS
or
