68
6.1 Trouble Indication
EKB2
Message TBL displayed in the lower left side of the main screen view indicates presence of system troubles.
In order to nd out more on the particular system problem, please, open menu section TROUBLES. The description on
each system problem is indicated in the table below.
Menu path:
OK → TROUBLES → T [1... 6]
Trouble Name Description
TROUBLE 1 VIOLATED TAMPER One or more tampers are violated.
TROUBLE 2 REPLACE BATTERY Backup battery problem.
TROUBLE 3 AC FAILURE Main power supply problem.
TROUBLE 4 TIME NOT SET Date/time not set.
TROUBLE 5 HIZONES One or more high zones (Z13 -
Z44) are violated.
TROUBLE 6 GSM ERROR GSM connection problem.
6. Technical Support
