MANUAL ELDES ESIM264 V2.0 69
Yellow LED SYSTEM indicates system troubles. SYSTEM LED indications are mentioned in the table below.
SYSTEM LED Description
Illuminated continously One ore more zones or tampers are vio-
lated; other system troubles
Flashing One or more high zones are violated
In order to nd out more on the particular system problem, please, enter command A. After this procedure the system
will activate red zone LEDs for 15 seconds. The description on each LED indication is mentioned in the table below.
Zone LED Description
1 One or more tampers are violated.
2 Backup battery problem.
3 Main power supply problem.
4 Date/time not set.
5 One or more high zones (Z13 - Z44) are violated.
6 GSM connection problem.
In order to nd out which particular high zone is violated, please, enter command B.
In order to nd out which particular tamper is violated, please, enter command C.
A. System trouble indication - enter command:
[CODE#]
B. Violated high zone indication – enter command:
[CODE1]
C. Violated tamper indication – enter command:
[CODE2]
The number of violated high zone or tamper can be calculated using the table below according to the formula: number
from zone LED section B + number from zone LED section A.
Example: LED #3 from section A is ashing and LED #8 from section B is illuminated continuously. According to the table
below LED #8 is equal to number 18, therefore 18 + 3 = 21.
Result: Violated high zone or tamper number is 21.
Zone LED section - A
(ashing)
Zone LED section - B
(illuminated continously)
Zone LED 1 = 1 Zone LED 7 = 12
Zone LED 2 = 2 Zone LED 8 = 18
Zone LED 3 = 3 Zone LED 9 = 24
Zone LED 4 = 4 Zone LED 10 = 30
Zone LED 5 = 5 Zone LED 11 = 36
Zone LED 6 = 6 Zone LED 12 = 42
EKB3
