MANUAL ELDES ESIM264 V2.0 37
SMS
SMS text:
XXXX_Zn:OFF
Value: Zn – zone number, range – [Z1... Z44]
Example: 1111_Z4:OFF
EKB2
Menu path:
OK → CONFIGURATION → ZONES → WIRED ZONES → [ZONE 1... 12] → STATUS → DISABLE
OK → CONFIGURATION → ZONES →
WIRELESS ZONES → RF ZONE [1... 16] → STATUS → DISABLE
OK → CONFIGURATION → ZONES →
KEYBOARD ZONES → [1ST... 4TH] KEYBOARD ZONE → STATUS → DISABLE
OK → CONFIGURATION → ZONES →
EPGM ZONES → EPGM ZONE [1... 16] → STATUS → DISABLE
EKB3
Enter parameter 52 & parameter status value:
[52xx0#]
Value: xx – zone number, range – [01... 44]
SMS
SMS text:
XXXX_Zn:ON
Value: Zn – zone number, range – [Z1... Z44]
Example: 1111_Z3:ON
EKB2
Menu path:
OK → CONFIGURATION → ZONES → WIRED ZONES → [ZONE 1... 12] → STATUS → ENABLE
OK → CONFIGURATION → ZONES →
WIRELESS ZONES → RF ZONE [1... 16] → STATUS → ENABLE
OK → CONFIGURATION → ZONES → KEYBOARD ZONES → [1ST... 4TH] KEYBOARD ZONE →
STATUS → ENABLE
OK → CONFIGURATION → ZONES →
EPGM ZONES → EPGM ZONE [1... 16] → STATUS → ENABLE
EKB3
Enter parameter 52 & parameter status value:
[52xx1#]
Value: xx – zone number, range – [01... 44]
This command disables a particular zone. By default, all on-board zones, EPGM1 zones and
wi reless zones are enabled.
This command enables a particular zone. By default, all keyboard zones and virtual zones are
disabled.
Virtual zones can be enabled using ELDES Conguration Tool only.
Disable Zone
Enable Zone
