232 Using the Control Panel
Parallel I/F
Allows you to activate or deactivate the parallel interface.
Speed
Specifies the pulse width of the ACKNLG signal when receiving
data in the Compatibility mode or Nibble mode. When Fast is
selected, the pulse width is about 1 ms. When Normal is selected,
the pulse width is about 10 ms.
Bi-D
Allows you to specify the bidirectional communication mode.
When you select Off, bidirectional communication is disabled.
Buffer Size
Determines the amount of memory to be used for receiving data
and printing data. If Maximum is selected, more memory is
allocated for receiving data. If Minimum is selected, more memory
is allocated for printing data.
Note:
❏ To activate Buffer Size settings, you must turn off the printer for
more than five seconds then turn it back on. Or, you can perform a
Reset All operation, as explained in "Reset Menu" on page 230.
❏ Resetting the printer erases all print jobs. Make sure the Ready
light is not flashing when you reset the printer.
Parallel I/F On, Off
Speed Fast, Normal
Bi-D Nibble, ECP, Off
Buffer Size Normal, Maximum, Minimum
To Next Page
