217
Appendix
*1: If the gap is 3 mm or less, you need to adjust the detector.
*2: Any other marks should not be placed in the blank between pages.
Winding direction Print side must be facing outside (facing inside is unusable)
Black mark position 18.4 mm or more away from the side edge baseline
Black mark width 18.4 mm or more
Black mark length 4 to 25.4 mm, 4 mm or more of blank space on label
Black mark interval The same as the gap between pages*2
• Paper with holes or cutouts cannot be used.
• Set the cut position to a position at least 1.7 mm away from the black mark of the next label.
