220
Appendix
*1: If the gap is 3 mm or less, you need to adjust the detector.
*2: Black marks cannot be placed in the blank space between pages.
Black mark length 4 to 25.4 mm, 4 mm or more of blank space on label
Black mark interval The same as the gap between pages*2
Perforation interval Three (hole portion) to one (no hole portion)
Perforation form Usable if a hole is located at side edges
• Paper with holes or cutouts cannot be used.
• Auto cutting on the perforated lines will generate scraps of paper that may cause problems. Also,
auto cutting ahead of the perforated line may cause problems when feeding paper. Therefore, per-
form auto cutting when paper is fed at least 0.8 mm away from the perforated line.
• Set the black mark position to a position at least 2.5 mm away from the perforated line.
• Set the cut position to a position at least 1.7 mm away from the black mark of the next label.
