230
Appendix
Roll Die-cut Label (without Black Mark)
Form Roll paper
Backing paper width 25.4 to 215.9 mm
Label width 21.4 to 211.9 mm
Label length When peeler is not used: 8 to 609.6 mm (up to 24 inches)
When peeler is used: 12.7 to 609.6 mm (up to 24 inches)
Gap between Labels 2 to 6 mm
Waste part on the left and right 2 ± 0.5 mm
Label corner R 1.5 mm or more
Paper thickness Matte Paper: 0.178 mm
Synthetic: 0.229 mm
Glossy Paper: 0.174 mm
Glossy Film: 0.164mm
High Glossy Paper: 0.188mm
Roll paper core inner diameter 76.2 mm ± 0.5 mm
Roll paper outer diameter 152.4 mm or less
Winding direction Print side must be facing outside (facing inside is unusable)
Waste part
Label length
Gap between Labels
Waste part
Backing paper
Label area
Backing paper width
Paper feed direction
Gap between pages
Label width
Side edge baseline
